PERFORMANCE TABLE
Borewell Size :100MM
Sr. No. Pump Type HP. Stage Delivery Size 38 mm (1.5”) Performance Values Method of Starting Method of Starting
Discharge in L.P.M.
66 76 91 103 126 145 162
1 NV45 3 18 Total Head in Meters 90 86 79 72 58 43 18 CAPACITER START CAPACITER RUN DOL
2 NV45 3 20 100 96 88 80 64 48 20
Sr. No. Pump Type HP. Stage Delivery Size 38 mm (1.5”) Performance Values Method of Starting Method of Starting
Discharge in L.P.M.
113 121 133 142 161 179 195
1 NV47 3 15 Total Head in Meters 75 72 66 60 48 36 15 CAPACITER STARTCAPACITER RUN DOL
2 NV47 5 25 125 120 110 100 80 60 25
Sr. No. Pump Type HP. Stage Delivery Size 50 mm (2.0”) Performance Values Method of Starting Method of Starting
Discharge in L.P.M.
30 70 95 150 180 210 250
1 NVM412 3 10 Total Head in Meters 48 44 40 30 20 10 3 CAPACITER STARTCAPACITER RUN DOL
2 NVM412 3 12 58 53 48 36 24 12 4
3 NVM412 5 20 96 88 80 60 40 20 6
Sr. No. Pump Type HP. Stage Delivery Size 50 mm (2.0”) Performance Values Method of Starting Method of Starting
Discharge in L.P.M.
70 100 215 270 310 370 385
1 NVM418 3 7 Total Head in Meters 31 28 21 18 14 7 3 CAPACITER STARTCAPACITER RUN DOL
2 NVM418 3 9 40 36 24 24 18 9 4
3 NVM418 5 12 53 48 36 30 24 12 5
4 NVM418 5 14 62 56 42 35 28 14 6
