PERFORMANCE TABLE
Mix Flow
Borewell Size :130.0 mm
Pump O.D. :125.0 mm
Motor O.D.:120.0 mm
Sr. No. Pump Type HP. Stage Delivery Size 65 mm (2.5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
0 95 240 330 405 465 520
1 NM5-10 3 3 Total Head in Meters 29 27 24 21 18 15 12 DOL 1.5
2 NM5-10 4 4 38 36 32 28 24 20 16 DOL 1.5
3 NM5-10 5 5 48 45 40 35 30 25 20 DOL 2.5
4 NM5-10 6 6 58 54 48 42 36 30 24 DOL 2.5
5 NM5-10 7.5 8 77 72 64 56 48 40 32 DOL 2.5
6 NM5-10 10 10 96 90 80 70 60 50 40 S / D 2.5
Sr. No. Pump Type HP. Stage Delivery Size 65 mm (2.5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
0 263 405 485 552 614 668
1 NM5-12 3 2 Total Head in Meters 20 18 16 14 12 10 8 DOL 1.5
2 NM5-12 4 3 30 27 24 24 18 15 12 DOL 1.5
3 NM5-12 5 4 40 36 32 28 24 20 16 DOL 2.5
4 NM5-12 6 5 50 45 40 35 30 25 20 DOL 2.5
5 NM5-12 7.5 6 60 54 48 42 36 30 24 DOL 2.5
6 NM5-12 10 8 80 72 64 56 48 40 32 S / D 2.5
Sr. No. Pump Type HP. Stage Delivery Size 65 mm (2.5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
0 290 440 532 595 660 721
1 NM5-15 5 3 Total Head in Meters 30 27 24 21 18 15 12 DOL 2.5
2 NM5-15 6 4 40 36 32 28 24 20 16 DOL 2.5
3 NM5-15 7.5 5 50 45 40 35 30 25 20 DOL 2.5
4 NM5-15 10 6 60 54 48 42 36 30 24 S /D 2.5
5 NM5-15 10 7 70 63 56 49 42 35 28 S / D 2.5
