PERFORMANCE TABLE
Borewell Size :150.0 mm
Pump O.D. :142.0 mm
Motor O.D.:142.0 mm
Sr. No. Pump Type HP. Stage Delivery Size 63 mm (2.5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
60 155 325 395 470 590 720
1 NM6-10 3 3 Total Head in Meters 28 27 23 21 16 11 6 DOL 2.5
2 NM6-10 4 4 38 36 31 28 21 14 8 DOL 2.5
3 NM6-10 5 5 48 46 39 35 26 18 10 DOL 2.5
4 NM6-10 6 6 57 55 46 42 32 21 12 DOL 2.5
5 NM6-10 7.5 7 69 64 54 49 37 25 14 DOL / SD 4.0 / 2.5
6 NM6-10 7.5 8 76 73 62 56 42 28 16 DOL / SD 4.0 / 2.5
7 NM6-10 10 10 95 91 77 70 53 35 20 S / D 4
8 NM6-10 12.5 12 114 109 92 84 63 42 24 S / D 4
9 NM6-10 15 14 133 127 108 98 74 49 28 S / D 4
10 NM6-10 15 15 142 137 116 105 78 53 30 S / D 4
11 NM6-10 15 16 151 146 123 112 84 56 32 S / D 4
12 NM6-10 17.5 18 171 164 139 126 95 63 36 S / D 6
13 NM6-10 20 20 190 182 154 140 105 70 40 S / D 6
Sr. No. Pump Type HP. Stage Delivery Size 63 mm (2.5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
80 160 430 525 650 745 850
1 NM6-12 4 3 Total Head in Meters 28 27 23 21 16 11 6 DOL 2.5
2 NM6-12 5 4 38 36 31 28 21 14 8 DOL 2.5
3 NM6-12 6 5 48 46 39 35 26 18 10 DOL 2.5
4 NM6-12 7.5 6 57 55 46 42 32 21 12 DOL / SD 4.0 / 2.5
5 NM6-12 7.5 7 66 64 54 49 37 25 14 DOL / SD 4.0 / 2.5
6 NM6-12 10 8 76 73 62 56 42 28 16 S / D 4
7 NM6-12 10 9 85 82 69 63 47 32 18 S / D 4
8 NM6-12 12.5 10 95 91 77 70 53 35 20 S / D 4
9 NM6-12 15 12 114 109 92 84 63 42 24 S / D 4
10 NM6-12 17.5 14 133 127 108 98 74 49 28 S / D 6
11 NM6-12 17.5 15 143 136 115 105 79 53 30 S / D 6
12 NM6-12 20 16 151 146 123 112 84 56 32 S / D 6
13 NM6-12 22.5 18 171 164 139 126 95 63 36 S / D 6
14 NM6-12 25 20 191 180 151 140 105 70 40 S / D 10
Sr. No. Pump Type HP. Stage Delivery Size 63 mm (2.5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
170 375 600 650 770 870 960
1 NM6-15 3 2 Total Head in Meters 20 18 15 14 11 7 4 DOL 2.5
2 NM6-15 5 3 29 27 23 20 16 11 6 DOL 2.5
3 NM6-15 6 4 39 36 31 28 21 14 8 DOL 2.5
4 NM6-15 7.5 5 49 46 39 35 26 18 10 DOL / SD 4.0 / 2.5
5 NM6-15 10 6 59 55 46 42 32 21 12 S / D 4
6 NM6-15 10 7 69 64 54 49 37 25 14 S / D 4
7 NM6-15 12.5 8 79 73 62 56 42 28 16 S / D 4
8 NM6-15 15 9 97 82 69 63 47 32 18 S / D 4
9 NM6-15 15 10 99 91 77 70 53 35 20 S / D 4
10 NM6-15 17.5 12 118 109 92 84 63 42 24 S / D 6
11 NM6-15 20 13 128 118 100 91 68 47 28 S / D 6
12 NM6-15 22.5 15 143 136 115 105 79 53 30 S / D 6
13 NM6-15 25 16 151 146 123 112 84 56 32 S / D 10
Sr. No. Pump Type HP. Stage Delivery Size 75 mm (3”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
300 625 760 840 980 1070 1150
1 NM6-20 4 2 Total Head in Meters 22 18 15 14 11 7 4 DOL 2.5
2 NM6-20 6 3 34 27 23 21 16 11 8 DOL 2.5
3 NM6-20 7.5 4 45 36 31 28 21 14 11 DOL / SD 4.0 / 2.5
4 NM6-20 10 5 56 46 39 35 26 18 13 S / D 4
5 NM6-20 12.5 6 67 55 46 42 32 21 16 S / D 4
6 NM6-20 15 7 78 64 54 49 37 25 19 S / D 4
7 NM6-20 15 8 90 73 62 56 42 28 21 S / D 4
8 NM6-20 17.5 9 111 82 69 63 49 32 24 S / D 6
9 NM6-20 20 10 112 91 77 70 53 35 27 S / D 6
10 NM6-20 25 12 118 109 92 84 63 42 24 S / D 10
Sr. No. Pump Type HP. Stage Delivery Size 75 mm (3”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
240 480 770 890 1070 1200 1330
1 NM6-25 5 2 Total Head in Meters 22 20 18 16 12 8 3 DOL 2.5
2 NM6-25 7.5 3 34 30 26 24 18 12 4 DOL / SD 4.0 / 2.5
3 NM6-25 10 4 45 40 35 32 24 16 5 S / D 4
4 NM6-25 12.5 5 56 50 44 40 30 20 7 S / D 4
5 NM6-25 15 6 67 60 53 48 36 24 8 S / D 4
6 NM6-25 17.5 7 78 70 62 56 42 28 9 S / D 6
7 NM6-25 20 8 90 80 70 64 48 32 11 S / D 6
8 NM6-25 22.5 9 101 90 79 72 54 36 12 S / D 6
9 NM6-25 25 10 112 100 88 80 60 40 13 S / D 10
Sr. No. Pump Type HP. Stage Delivery Size 75 mm (3”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
280 600 970 1100 1260 1380 1470
1 NM6-30 6 2 Total Head in Meters 24 20 18 16 12 8 4 DOL 2.5
2 NM6-30 10 3 35 30 26 24 18 12 5 S / D 4
3 NM6-30 12.5 4 47 40 35 32 24 16 7 S / D 4
4 NM6-30 15 5 59 50 44 40 30 20 9 S / D 4
5 NM6-30 17.5 6 71 60 53 48 36 24 11 S / D 6
6 NM6-30 20 7 82 70 62 56 42 28 12 S / D 6
7 NM6-30 25 8 93 80 71 64 48 32 13 S / D 10
Sr. No. Pump Type HP. Stage Delivery Size 75 mm (3”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
425 700 1100 1190 1400 1550 1780
1 NM6-40 7.5 2 Total Head in Meters 24 20 18 16 12 8 3 DOL / SD 4.0 / 2.5
2 NM6-40 12.5 3 35 30 26 24 18 12 5 S / D 4
3 NM6-40 17.5 4 47 40 35 32 24 16 7 S / D 6
4 NM6-40 20 5 59 50 44 40 30 20 9 S / D 6
5 NM6-40 25 6 71 60 43 48 36 24 11 S / D 10
